What is Technical Analysis?

01

Technical Analysis (TA) is the study of past price and volume data to forecast future price movements. Unlike fundamental analysis which looks at economic data, TA focuses solely on what the chart tells us — patterns, trends, and momentum.

📌 Three Core Assumptions

▸Price discounts everything — all known information is already reflected in price
▸Price moves in trends — markets trend up, down, or sideways
▸History repeats — patterns that worked before tend to recur

✅ What TA Can Do

✓Identify trend direction
✓Find key support/resistance levels
✓Signal potential reversals
✓Define entry, stop loss, and target
✓Measure momentum and volatility

⚠️ What TA Cannot Do

✗Predict the future with certainty
✗Replace news events (fundamentals)
✗Work 100% of the time
✗Remove all trading risk
✗Substitute for proper risk management

Key insight: TA is a tool for probability, not certainty. A good setup gives you a better-than-random chance of success — it does not guarantee a win. Combine TA with solid risk management for consistent results.

history_edu

Dow Theory

02

Developed by Charles Dow in the late 1800s, Dow Theory is the foundation of modern technical analysis. It defines how markets move and how trends are identified.

6 Tenets of Dow Theory

1.The averages discount everything
2.The market has three trends (Primary, Secondary, Minor)
3.Primary trends have three phases
4.Averages must confirm each other
5.Volume confirms the trend
6.A trend is in effect until reversed

Three Phases of a Bull Market

①Accumulation Phase: Smart money buys quietly while retail is pessimistic
②Public Participation Phase: Most traders join; price rises rapidly
③Distribution Phase: Smart money sells to the euphoric public

Uptrend definition: A series of Higher Highs (HH) and Higher Lows (HL).
Downtrend definition: A series of Lower Highs (LH) and Lower Lows (LL).

area_chart

Types of Charts

03

〰️ Line Chart

Connects closing prices with a simple line. Best for identifying the overall trend but lacks detail about price action within each period.

📊 Bar Chart (OHLC)

Shows Open, High, Low, Close with vertical bars and tick marks. Provides more detail than line charts. Used widely in traditional markets.

🕯️ Candlestick Chart

Originated in Japan. Shows OHLC in a visual "candle" format — body shows open/close, wicks show high/low. The most popular chart type in Forex.

Timeframes: The same candlestick forms on any timeframe — M1, M5, M15, H1, H4, D1, W1. A D1 candle represents one full day's price action. Use higher timeframes for trend, lower timeframes for entry precision.

candlestick_chart

Candlestick Patterns

04

A candlestick = Body (open → close) + Upper wick + Lower wick. A green/white candle closes higher than it opens (bullish). A red/black candle closes lower than it opens (bearish).

🔨

Hammer

Bullish Reversal

Small body at top, long lower wick. Buyers rejected sellers strongly.

☄️

Shooting Star

Bearish Reversal

Small body at bottom, long upper wick. Sellers rejected buyers strongly.

✝️

Doji

Indecision

Open ≈ Close. Neither buyers nor sellers in control. Watch for next candle.

🟢

Bullish Engulfing

Strong Bullish

Large green candle engulfs previous red candle. Strong buying momentum.

🔴

Bearish Engulfing

Strong Bearish

Large red candle engulfs previous green candle. Strong selling momentum.

⭐

Morning Star

Bullish Reversal

3-candle pattern: red → small body → strong green. Bottom reversal signal.

🌙

Evening Star

Bearish Reversal

3-candle pattern: green → small body → strong red. Top reversal signal.

👀

Harami

Reversal Warning

Small candle inside the body of the previous larger candle. Potential reversal.

🕯️

Marubozu

Trend Continuation

Candle with no wicks. Full control by buyers (green) or sellers (red).

horizontal_rule

Support & Resistance

05

🟢 Support Level

A price zone where buying pressure is strong enough to stop or reverse a downtrend. The market has "bounced" from this level multiple times. Think of it as the floor.

🔴 Resistance Level

A price zone where selling pressure is strong enough to stop or reverse an uptrend. The market has been "rejected" from this level multiple times. Think of it as the ceiling.

🔄 Role Reversal — Support Becomes Resistance

Once a support level is broken, it often becomes a new resistance level — and vice versa. This is one of the most reliable concepts in technical analysis. The more times a level has been tested, the more significant it becomes.

Zones, not lines: Support and resistance are best treated as zones (a range of 5–20 pips), not exact price lines. Price rarely reverses at the exact same pip twice. Drawing them as zones reduces false signals.

trending_up

Trend Lines & Channels

06

📈 Uptrend Line

Draw along Higher Lows. Price bounces off the line upward. A break below this line signals a potential trend reversal.

📉 Downtrend Line

Draw along Lower Highs. Price is rejected by the line downward. A break above signals a potential reversal to the upside.

↔️ Channel

Two parallel trend lines forming a price corridor. Buy at the lower line, sell at the upper line — or trade the breakout when price exits.

Rule: A valid trend line requires at least 2 touches — but 3 or more touches make it much more reliable. The steeper the angle of a trend line, the more likely it is to break quickly.

category

Chart Patterns

07

Chart patterns are recurring formations on price charts that signal either a continuation of the current trend or a reversal. They are formed by the natural psychology of market participants.

🔄 Reversal Patterns

▸Head & Shoulders — Bearish reversal. Three peaks with the middle (head) highest. Break of neckline triggers sell.
▸Inverse H&S — Bullish reversal. Mirror image of above. Break of neckline triggers buy.
▸Double Top — Bearish. Two equal highs at resistance. Confirms on break below the valley.
▸Double Bottom — Bullish. Two equal lows at support. Confirms on break above the peak.
▸Triple Top/Bottom — Stronger version; three tests before breaking out.

➡️ Continuation Patterns

▸Ascending Triangle — Flat top + rising lows → bullish breakout expected
▸Descending Triangle — Flat bottom + falling highs → bearish breakout expected
▸Symmetrical Triangle — Converging lines → neutral; break in trend direction
▸Bull Flag / Bear Flag — Sharp move → consolidation → continuation
▸Pennant — Like a flag but with converging lines
▸Wedge — Rising wedge = bearish; Falling wedge = bullish

Target calculation: For most chart patterns, the price target after breakout = height of the pattern measured from the breakout point. Always confirm breakout with increased volume.

show_chart

Moving Averages

08

SMA — Simple Moving Average

Trend Indicator · Lagging

Average of closing prices over N periods. Each period weighted equally. Slower to react. Common periods: 20, 50, 100, 200.

EMA — Exponential Moving Average

Trend Indicator · Less Lagging

Gives more weight to recent prices. Reacts faster to price changes. Popular periods: 9, 12, 21, 26, 50. Preferred by most active traders.

📍 Key MA Trading Signals

▸Price above MA → Bullish trend. Look for buy setups on pullbacks to the MA.
▸Price below MA → Bearish trend. Look for sell setups on bounces to the MA.
▸Golden Cross → 50 EMA crosses above 200 EMA → Strong bullish signal
▸Death Cross → 50 EMA crosses below 200 EMA → Strong bearish signal
▸MA as Dynamic Support/Resistance → 20 EMA acts as trailing support in strong uptrends

electric_bolt

RSI — Relative Strength Index

09

The RSI is a momentum oscillator that measures the speed and change of price movements on a scale of 0 to 100. Developed by J. Welles Wilder. Default period: 14.

🔴 Overbought Zone (70+)

RSI above 70 means the asset may be overbought. In trending markets, RSI can stay above 70 for extended periods — don't just sell because RSI is high.

🟢 Oversold Zone (30−)

RSI below 30 means the asset may be oversold. A bounce back above 30 can signal the start of a recovery. Combine with support zones for better accuracy.

💜 RSI Divergence

Bullish divergence: Price makes lower low but RSI makes higher low → reversal signal.
Bearish divergence: Price makes higher high but RSI makes lower high → reversal signal.

compare_arrows

MACD

10

MACD (Moving Average Convergence Divergence) shows the relationship between two EMAs. Components: MACD Line (12 EMA − 26 EMA) · Signal Line (9 EMA of MACD) · Histogram (MACD − Signal).

📍 MACD Trading Signals

▸Bullish crossover: MACD line crosses above signal line → Buy
▸Bearish crossover: MACD line crosses below signal line → Sell
▸Zero-line cross up: MACD crosses above 0 → trend turned bullish
▸Zero-line cross down: MACD crosses below 0 → trend turned bearish
▸Histogram expanding: Momentum strengthening in that direction

💡 MACD Tips

▸MACD is a lagging indicator — signals appear after the move starts
▸Works best in trending markets; generates false signals in ranging markets
▸Combine with RSI to filter overbought/oversold conditions
▸Look for MACD divergence from price for strongest signals

adjust

Bollinger Bands

11

Created by John Bollinger. Three lines: Middle Band (20 SMA) + Upper Band (Middle + 2 std dev) + Lower Band (Middle − 2 std dev). Approximately 95% of price action falls within the bands.

📉 Band Squeeze

When bands narrow significantly, it signals low volatility and a potential big move ahead. The squeeze itself doesn't tell you the direction — watch for the breakout.

↔️ Band Walk

In strong trends, price can "walk" along the upper or lower band for extended periods. Don't fade the trend just because price touched the outer band.

🔄 Mean Reversion

In ranging markets, price tends to return to the middle band after touching either outer band. Works well in consolidation, dangerous in trending markets.

all_inclusive

Fibonacci Retracement

12

Fibonacci levels are horizontal price levels derived from the Fibonacci sequence. They identify where price may retrace before continuing in the original direction. Key levels: 23.6% · 38.2% · 50% · 61.8% · 78.6%. The golden ratio 61.8% is the most respected.

📐 How to Draw Fibonacci

①Identify a clear swing high and swing low
②In an uptrend: drag from swing low → swing high
③In a downtrend: drag from swing high → swing low
④Look for price to stall at 38.2%, 50%, or 61.8%
⑤Confirm with support/resistance or candlestick pattern

💡 Fibonacci + Confluence

A Fibonacci level becomes much stronger when it aligns with:

Support/Resistance Moving Average Trend Line Round Number Previous High/Low

The more confluences at a level, the higher the probability of a reversal there.

waves

Elliott Wave Theory

13

Developed by Ralph Nelson Elliott. States that market prices move in repetitive wave patterns driven by investor psychology. A complete market cycle = 5 impulse waves + 3 corrective waves.

📈 Impulse Waves (1-2-3-4-5)

W1Initial move up (often mistaken for a bounce)
W2Retracement (never goes below Wave 1 start)
W3Longest and strongest wave — best to trade
W4Shallow correction (rarely overlaps with Wave 1)
W5Final push — often weaker, divergence appears

📉 Corrective Waves (A-B-C)

AFirst leg down — still seen as temporary by many
BRetracement up — traps late buyers ("bull trap")
CFinal leg down — often equal to or longer than Wave A

Key rule: Wave 3 can never be the shortest impulse wave.

cloud

Ichimoku Cloud

14

The Ichimoku Kinko Hyo ("equilibrium at a glance") is a comprehensive indicator showing trend direction, momentum, and support/resistance levels — all in one chart. Developed in Japan in the 1960s.

📌 Five Components

▸Tenkan-sen (9): Conversion line — fast trend signal
▸Kijun-sen (26): Base line — medium trend signal
▸Senkou Span A: Leading span A — forms cloud edge
▸Senkou Span B (52): Leading span B — forms other cloud edge
▸Chikou Span: Lagging span — current close plotted 26 bars back

☁️ Cloud (Kumo) Signals

▸Price above cloud → Bullish trend
▸Price below cloud → Bearish trend
▸Price inside cloud → Consolidation / no clear trend
▸Price crosses cloud upward → Strong buy signal
▸Price crosses cloud downward → Strong sell signal
▸Thin cloud → weak support/resistance; Thick cloud → strong

stacked_bar_chart

Volume Analysis

15

Volume measures the number of units (lots) traded during a given period. It is one of the few leading indicators — rising volume often confirms the strength of a move, while falling volume warns of weakening momentum.

✅ Volume + Price Combinations

▸Price up + Volume up → Strong bullish confirmation
▸Price down + Volume up → Strong bearish confirmation
▸Price up + Volume down → Weak rally, possible reversal ahead
▸Price down + Volume down → Weak selloff, possible bounce ahead

🔍 Key Volume Signals

▸Volume climax / exhaustion: Huge spike in volume often marks the end of a trend
▸Breakout + volume surge: Confirms the breakout is genuine, not a fakeout
▸Low volume pullback: In a trend, pullbacks on low volume suggest trend continuation

swap_vert

Divergence Trading

16

Divergence occurs when the price chart and an indicator (typically RSI or MACD) move in opposite directions. It's one of the most powerful signals for identifying potential trend reversals before they happen.

🟢 Bullish Divergence

Price makes a Lower Low but the indicator makes a Higher Low.

Meaning: Selling momentum is weakening even as price falls. A reversal upward is likely. Best found at key support zones.

🔴 Bearish Divergence

Price makes a Higher High but the indicator makes a Lower High.

Meaning: Buying momentum is weakening even as price rises. A reversal downward is likely. Best found at key resistance zones.

Hidden Divergence (Continuation signal):
• Hidden Bullish: Price makes Higher Low, indicator makes Lower Low → trend continuation upward
• Hidden Bearish: Price makes Lower High, indicator makes Higher High → trend continuation downward

layers

Multi-Timeframe Analysis

17

Multi-Timeframe Analysis (MTF) means analyzing the same currency pair on multiple timeframes to get the full picture. Trade in the direction of the higher timeframe trend, and enter on the lower timeframe for precision.

🔭 Higher Timeframe (HTF)

D1 / W1 — Defines the dominant trend. Identifies major support/resistance. This is your "bias" — only trade in this direction.

⚙️ Middle Timeframe

H4 / H1 — Refines the setup. Confirms the trend and shows key zones where price is likely to react. Identifies your trading area.

🎯 Lower Timeframe (LTF)

M15 / M5 — Entry precision. Look for your trigger (pattern, signal) at the level identified on the HTF. Tighter stops, better risk-reward.

"Trade on the timeframe that matches your lifestyle — but always know what the higher timeframe is doing."

ads_click

Price Action Trading

18

Price Action is the art of reading and trading from raw price movement — no indicators, only candlesticks, structure, and key levels. Many professional traders consider it the purest form of market analysis.

📌 Core Price Action Concepts

▸Pin Bar (Pinocchio Bar): Long wick rejecting a key level — powerful reversal signal
▸Inside Bar: Bar contained within the previous bar's range — breakout setup
▸Outside Bar (Fakey): False break of inside bar — traps traders
▸Consolidation + Breakout: Price ranges, then breaks — trade the break
▸Strong close: Candle that closes near its high/low shows conviction

🎯 Why Traders Choose Price Action

✓Works on any market and any timeframe
✓No indicator lag — pure real-time reading
✓Helps understand market psychology directly
✓Simple charts → clearer thinking
✗Requires screen time and pattern recognition skill
✗Subjective — two traders may read the same chart differently

account_tree

Market Structure

19

Market Structure is the pattern of highs and lows that price creates over time. Reading structure tells you whether the market is in an uptrend, downtrend, or ranging — and when that changes.

📈 Bullish Structure

Higher Highs (HH) + Higher Lows (HL). Each swing high breaks above the previous, each swing low holds above the previous. Buy pullbacks to HL zones.

📉 Bearish Structure

Lower Highs (LH) + Lower Lows (LL). Each swing low breaks below the previous, each rally fails below the previous high. Sell bounces to LH zones.

↔️ Ranging Market

Price oscillates between a defined high and low with no clear direction. Wait for a confirmed breakout above resistance or below support before trading the trend.

Break of Structure (BOS): When price breaks a key swing high in a downtrend or a swing low in an uptrend, it signals a potential change of character (ChoCH) — the first sign of trend reversal.

view_module

Order Blocks & Liquidity Zones

20

Order Blocks are price zones where large institutional orders were placed. When price returns to these zones, the institution defends their positions — causing strong reactions. They are the footprints of "smart money."

🟢 Bullish Order Block

The last bearish (red) candle before a strong bullish impulse move. When price returns to this zone, expect buyers to step in again. Best traded on H1–H4 timeframes after a retracement.

🔴 Bearish Order Block

The last bullish (green) candle before a strong bearish impulse move. When price returns to this zone, expect sellers to step in again. Combine with HTF resistance for best results.

💧 Liquidity Concepts

▸Equal highs/lows: Price typically sweeps above/below equal levels (hunting stop losses) before reversing
▸Previous session highs/lows: Major liquidity pools — institutions target these before reversing direction
▸Stop hunt / Liquidity grab: Price briefly spikes through a key level, triggers stops, then reverses — this is the real entry signal

lightbulb

Smart Money Concepts (SMC)

21

Smart Money Concepts is a framework for understanding how institutional traders (banks, hedge funds) move markets. Rather than using retail indicators, SMC traders follow the flow of institutional money through price action and market structure.

🏦 Key SMC Concepts

▸Inducement: A fake breakout that traps retail traders before the real move
▸Fair Value Gap (FVG): A price gap where the market moved too fast; tends to be revisited
▸Premium / Discount: Price above 50% of range = premium (look to sell); below = discount (look to buy)
▸CISD (Change in State of Delivery): Shift from bearish to bullish delivery (or vice versa)

📍 SMC Trade Framework

①Identify HTF trend and bias
②Wait for liquidity sweep (stop hunt)
③Confirm Change of Character (ChoCH)
④Find Order Block / FVG in the new direction
⑤Enter on LTF confirmation at POI
⑥Target next liquidity pool

gps_fixed

Entry & Exit Strategies

22

🟢 Entry Triggers

▸Candlestick confirmation at key level (pin bar, engulfing)
▸Break + retest of structure or trend line
▸LTF change of character at HTF POI
▸Indicator confirmation (RSI cross, MACD signal)
▸Multiple confluences at the same level

🔴 Exit Rules

▸Stop loss: Below the structure low (for buys) or above the structure high (for sells)
▸Take profit: Previous high/low, next key level, or R:R target
▸Trail stop: Move stop to breakeven when 1R is hit; trail behind structure
▸Partial close: Take 50% at first target, let remainder run

Minimum R:R ratio: Only take trades with at least 1:2 Risk-to-Reward. This means for every $1 you risk, you aim to make $2. With a 40% win rate and 1:2 R:R, you are profitable.

assignment

Backtesting & Trading Journal

23

Backtesting is the process of testing a trading strategy against historical data to evaluate its performance before risking real money. A trading journal records every live trade to identify strengths and weaknesses.

📊 What to Track in Your Journal

▸Date & time of entry/exit
▸Currency pair and timeframe
▸Entry price, stop loss, take profit
▸Lot size and risk % per trade
▸Reason for entry (your setup criteria)
▸Result: Win / Loss / Breakeven + pips / $
▸Screenshot of chart at entry and exit
▸Emotional state and lessons learned

📈 Key Metrics to Monitor

▸Win Rate: % of trades that are winners
▸Average R:R: Avg winner ÷ avg loser
▸Expectancy: (Win% × Avg Win) − (Loss% × Avg Loss)
▸Max Drawdown: Largest peak-to-trough equity decline
▸Profit Factor: Gross profit ÷ Gross loss (target: above 1.5)

"A strategy without backtesting is just a theory. A trade without journaling is just gambling. Document everything — your future self will thank you."

MasterTechnical Analysis

Master
Technical Analysis
